2019 Year

134 kW

Diesel Fuel

Loading capacity Ton: 25 ton

Finance: Not available

GVW 25000 kg
Wheelbase 4000 mm
TCD (M) 15.8
Max Power 180 hp @ 2500 rpm
Max Torque 685 Nm @1500 rpm
Clutch Type Coil spring push type
Clutch Diameter 380 mm
Gearbox ZF 1110TD, 8 Forward, 1 Crawler & 1 Reverse
Front Axle Reverse Elliot type I beam
Rear Axle Meritor Axle
Chassis Type Rolled C-channel straight frame, 285x76x6 mm
Suspension Front: Semi elliptical laminated leaf springs w/o Anti roll bar
Rear: Bogie suspension / Crank Suspension
Steering Hydraulic Power Steering
Gradiability 43% 12 V
Max Speed 70 kmph
Fuel Tank 220 litres
Electrical 24 V
Tyre 10x20-16PR
Body size & type 14 & 16 CuM , Box Type
